TERTA Digital Micro Repeater/BDA
Model: 02711D
Product Details
Multi-band support offers flexibility to meet various network demands.
Fine-grained control is achieved through individual sub-band activation/deactivation.
Intelligent algorithms effectively mitigate uplink interference.
Independent gain control further optimizes performance.
Self-control mechanisms minimize interference during new base station deployments.
NMS facilitates remote/local control and monitoring.
Specification
P/N: 02711D | TETRA | |
Frequency Range | Uplink (adjustable) | 380- 385MHz |
Downlink (adjustable) | 390-395MHz | |
Number of Sub-bands | 1 | |
Bandwidth | 200kHz-5MHz/200kHz (adjustable) | |
Max. Gain | Uplink | 80±3 dB |
Downlink | 80±3 dB | |
Manual Gain Control | 31 dB in step of 1 dB | |
Automatic Gain Control | ≧ 20 dB | |
Gain Flatness (per sub-band) | ≦ ±1.5 dB (peak-to-peak) | |
Max. Input Power Without Damage | 0 dBm | |
Output Power | Uplink | 23±2 dBm |
Downlink | 27±2 dBm | |
Out of Band Gain | 1.6≤f_offset_CW<5.0 MHz | ≤20 dB |
Spurious Emission | 9KHz-1GHz | ≦ -36dBm |
1GHz-12.75GHz | ≦ -30dBm | |
ACRR | ±10/20MHz | ≦-36dBc/30KHz |
±20/40MHz | ≦-40dBc/30KHz | |
EVM | ≦ 8% | |
3rd Intermodulation | ≦ -45dBc | |
Frequency Stability | ≦ ±0.01 ppm | |
Noise Figure | ≦ 6 dB | |
VSWR | ≦ 1.5 | |
System Delay | ≦ 2 µs | |
RF Connector | N-Female | |
Impedance | 50 Ω | |
Power Supply | AC 110/ 220 V, 50/ 60 Hz | |
Power Consumption | 40 W | |
Dimensions | 430*365*130mm | |
Weight | ≦ 7 kgs | |
IP Rating | IP65 | |
Operating Temperature | -10 °C to 50 °C | |
Control & Monitoring | Local | Via USB Type C |
Remote | Via cloud-based NMS (optional) | |
