Private 5G
N77 Single Band-adjustable Digital Repeater
Model: 53711D.77
NSA/SA Support: Compatible with both Non-Standalone and Standalone 5G networks.
Accurate Synchronization: Built-in 5G base band synchronous detection module (SDM) ensures precise timing with the donor base station.
Multi-band support offers flexibility to meet various network demands.
Fine-grained control is achieved through individual sub-band activation/deactivation.
Intelligent algorithms effectively mitigate uplink interference.
Independent gain control further optimizes performance.
Self-control mechanisms minimize interference during new base station deployments.
NMS facilitates remote/local control and monitoring.
Product Details
Specification
P/N: 53711D.77 | N77 (3700) | |
Frequency Range | Uplink | 3800 - 4200 MHz (adjustable) |
Downlink | 3800 - 4200 MHz (adjustable) | |
Number of Sub-bands | 1 | |
Bandwidth per Sub-band | 5 - 100 MHz (adjustable) | |
Max. Gain | Uplink | 80±3 dB |
Downlink | 85±3 dB | |
Manual Gain Control | 31 dB in step of 1 dB | |
Automatic Gain Control | ≥20 dB | |
Gain Flatness (per sub-band) | ≤±3 dB (peak-to-peak) | |
Max. Input Power Without Damage | 0 dBm | |
Output Power | Uplink | 27±2 dBm |
Downlink | 37±2 dBm | |
Out of Band Gain | 2.5≤f_offset_CW< 5.0 MHz | ≤60 dB |
5.0≤f_offset_CW<10.0 MHz | ≤45 dB | |
10.0 MHz≤f_offset_CW | ≤35 dB | |
Spurious Emission | 9KHz-1GHz | ≤-36 dBm |
1GHz-12.75GHz | ≤-30 dBm | |
ACLR | ±10/20MHz | ≤-36 dBc/30kHz |
±20/40MHz | ≤-40 dBc/30kHz | |
EVM | ≤3.5 % | |
Frequency Stability | ≤±0.01 ppm | |
Noise Figure | ≤6 dB | |
VSWR | ≤1.5 | |
System Delay | ≤6㎲ | |
RF Connector | N-Female | |
Impedance | 50 Ω | |
Power Supply | 48 VDC or 230 VAC, 50/ 60 Hz | |
Power Consumption | ≤ 180 W | |
Dimensions | 630*408*222 mm | |
Weight | ≤20 kg | |
IP Rating | IP65 | |
Operating Temperature | -25 to 55 ℃ | |
NMS | Local | Via RJ45 |
Remote | Via Cloud-based NMS (optional) | |
