Private 5G

N79 Digital Band-adjustable Pico Repeater

Model: 52011D.79

Product Details

Automated Synchronization: Ensures seamless network integration.
NSA/SA Support: Compatible with both Non-Standalone and Standalone 5G networks.
RF Direct Sampling: The signal is digitized without down-conversion, preserving signal integrity and enabling wideband digital processing.
Cavity Filter: Superior out‑of‑band rejection, minimizing interference and ensuring clean, stable signal amplification.
Flexible sub-band management: Bandwidth is adjustable on demand, and individual sub-bands can be independently switched on/off for precise performance tuning.
NMS facilitates remote/local control and monitoring.

Specification

P/N: 52011D.79		N79 (4500)
Frequency Range	Uplink (adjustable)	4400-5000 MHz
	Downlink (adjustable)	4400-5000 MHz
Bandwidth (adjustable)		600 MHz
Number of Sub-bands		1
Sub-band Adjustment Range		5-100 MHz
Max. Gain	Uplink	70±3 dB
	Downlink	75±3 dB
Manual Gain Control		31 dB in step of 1 dB
Automatic Gain Control		≥ 30 dB in step of 1 dB
Gain Flatness (per sub-band)		≤ ±3.5 dB (peak-to-peak)
Max. Input Power Without Damage		-10 dBm
Output Power	Uplink	17±2 dBm
	Downlink	20±2 dBm
Out of Band Gain	0.2≤f_offset_CW< 1.0 MHz	≤60 dB
	1.0≤f_offset_CW<5.0 MHz	≤45 dB
	5.0≤f_offset_CW<10.0 MHz	≤45 dB
	10.0 MHz≤f_offset_CW	≤35 dB
Spurious Emission	9KHz-1GHz	≤ -36dBm
	1GHz-12.75GHz	≤ -30dBm
ACLR	±10/20MHz	≤ -36dBc/30KHz
	±20/40MHz	≤ -40dBc/30KHz
EVM		≤ 3.5%
IM3		-45 dBc
Frequency Stability		≤ ±0.01 ppm
Noise Figure		≤ 8 dB
VSWR		≤ 1.5
System Delay		≤ 6 µs
RF Connector		N-Female
Impedance		50 Ω
Power Supply	Input	AC 100~240 V, 50/ 60 Hz
	Output	DC 24 V/ 4.2 A
Power Consumption		≤ 65 W
Dimensions		330490120 mm
Weight		≤ 5 kg
IP Rating		IP40
Operating Temperature		-10 °C to 50 °C
NMS	Local	Via RJ45/SNMP
	Remote	Via Cloud-based NMS (optional)
