5G NR Repeater

5G/4G Triple Band-adjustable Digtial Pico Repeater (N78/B1/B3)

Model: 52013D

Product Details

NSA/SA Support: Compatible with both Non-Standalone and Standalone 5G networks.
Accurate Synchronization: Built-in 5G base band synchronous detection module (SDM) ensures precise timing with the donor base station.
Multi-band support offers flexibility to meet various network demands.
Fine-grained control is achieved through individual sub-band activation/deactivation.
Intelligent algorithms effectively mitigate uplink interference.
Independent gain control further optimizes performance.
Self-control mechanisms minimize interference during new base station deployments.
NMS facilitates remote/local control and monitoring.

Specification

P/N: 42013D.7813		B3 (1800)	B1 (2100)	N78 (3500)
Frequency Range	Uplink (adjustable)	1710-1785 MHz	1920-1980 MHz	3300-3600 MHz
	Downlink (adjustable)	1805-1880 MHz	2110-2170 MHz	3300-3600 MHz
Number of Sub-bands		1	1	1
Bandwidth per Sub-band		5- 75 MHz adjustable	5-60 MHz adjustable	5-100 MHz adjustable
Max. Gain	Uplink	70±2 dB	70±2 dB	70±2 dB
	Downlink	70±2 dB	70±2 dB	70±2 dB
Manual Gain Control		31 dB in step of 1 dB
Automatic Gain Control		≧ 20 dB
Gain Flatness (per sub-band)		≦ ±3.5 dB (peak-to-peak)
Max. Input Power Without Damage		0 dBm
Output Power	Uplink	20±2 dBm	20±2 dBm	20±2 dBm
	Downlink	20±2 dBm	20±2 dBm	20±2 dBm
Out of Band Gain	2.5≤f_offset_CW< 5.0 MHz	≤60 dB
	5.0≤f_offset_CW<10.0 MHz	≤45 dB
	10.0 MHz≤f_offset_CW	≤35 dB
Spurious Emission	9KHz-1GHz	≦ -36dBm
	1GHz-12.75GHz	≦ -30dBm
ACRR	±10/20MHz	≦-36dBc/30KHz
	±20/40MHz	≦-40dBc/30KHz
EVM		≦ 6%	≦ 8%	≦ 3.5%
Frequency Stability		≦ ±0.01 ppm
Noise Figure		≦ 8 dB
VSWR		≦ 2
System Delay		≦ 6 µs
RF Connector		N-Female
Impedance		50 Ω
Power Supply		Input: AC 100~240 V, 50/ 60 Hz; Output: DC 24 V/ 4.2 A
Power Consumption		≦ 70 W
Dimensions		33025895 mm
Weight		≦ 7 kgs
IP Rating		IP30
Operating Temperature		-10 °C to 50 °C
NMS	Local	Via Type-C/Wi-Fi App
	Remote	Via Cloud-based NMS (optional)
