5G NR Repeater
5G/4G Quad Band-adjustable Digital Pico Repeater (N78/B7/B3/B8)
Model: 52014D
Product Details
NSA/SA Support: Compatible with both Non-Standalone and Standalone 5G networks.
Accurate Synchronization: Built-in 5G base band synchronous detection module (SDM) ensures precise timing with the donor base station.
Multi-band support offers flexibility to meet various network demands.
Fine-grained control is achieved through individual sub-band activation/deactivation.
Intelligent algorithms effectively mitigate uplink interference.
Independent gain control further optimizes performance.
Self-control mechanisms minimize interference during new base station deployments.
NMS facilitates remote/local control and monitoring.
Specification
P/N: 42014D.78713 | B3 (1800) | B1 (2100) | B7 (2600) | N78 (3500) | |
Frequency Range | Uplink (adjustable) | 1710-1785 MHz | 1920-1980 MHz | 2500-2570 | 3300-3600 MHz |
Downlink (adjustable) | 1805-1880 MHz | 2110-2170 MHz | 2620-2690 | 3300-3600 MHz | |
Number of Sub-bands | 1 | 1 | 1 | 1 | |
Bandwidth per Sub-band (adjustable) | 5- 75 MHz | 5-60 MHz | 5-70 MHz | 5-100 MHz | |
Max. Gain | Uplink | 70±2 dB | 70±2 dB | 70±2 dB | 70±2 dB |
Downlink | 70±2 dB | 70±2 dB | 70±2 dB | 70±2 dB | |
Manual Gain Control | 31 dB in step of 1 dB | ||||
Automatic Gain Control | ≧ 20 dB | ||||
Gain Flatness (per sub-band) | ≦ ±3.5 dB (peak-to-peak) | ||||
Max. Input Power Without Damage | 0 dBm | ||||
Output Power | Uplink | 20±2 dBm | 20±2 dBm | 20±2 dBm | 20±2 dBm |
Downlink | 20±2 dBm | 20±2 dBm | 20±2 dBm | 20±2 dBm | |
Out of Band Gain | 2.5≤f_offset_CW< 5.0 MHz | ≤60 dB | |||
5.0≤f_offset_CW<10.0 MHz | ≤45 dB | ||||
10.0 MHz≤f_offset_CW | ≤35 dB | ||||
Spurious Emission | 9KHz-1GHz | ≦ -36dBm | |||
1GHz-12.75GHz | ≦ -30dBm | ||||
ACRR | ±10/20MHz | ≦-36dBc/30KHz | |||
±20/40MHz | ≦-40dBc/30KHz | ||||
EVM | ≦ 6% | ≦ 8% | ≦ 6% | ≦ 3.5% | |
Frequency Stability | ≦ ±0.01 ppm | ||||
Noise Figure | ≦ 8 dB | ||||
VSWR | ≦ 2 | ||||
System Delay | ≦ 6 µs | ||||
RF Connector | N-Female | ||||
Impedance | 50 Ω | ||||
Power Supply | Input: AC 100~240 V, 50/ 60 Hz; Output: DC 24 V/ 4.2 A | ||||
Power Consumption | ≦ 90 W | ||||
Dimensions | 330*258*95 mm | ||||
Weight | ≦ 9 kgs | ||||
IP Rating | IP30 | ||||
Operating Temperature | -10 °C to 50 °C | ||||
NMS | Local | Via USB Type-C | |||
Remote | Via Cloud-based NMS (optional) | ||||
